AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
1 / 5
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker

AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker

Send Inquiry

Product Description

MCCB Circuit Breaker 80A

Main Technical Parameters

  • Complete Current Range Frame Type: A (12.5~125A), B (32~160A), C (125~250A), D (250~400A), E (500~630A), F (400~800A), G (800~1250A), H (1600A)
  • High-Breaking Capacity Rated breaking capacity: B (20kA), C (35kA), S (50kA), H (65kA), G (85kA), X (100kA)
  • Rated Frequency 50/60Hz standard frequency configuration
  • Poles Configuration Available in 3P and 4P designs

Normal Working Environment

  • Ambient Temperature Safe operation range from -5°C to +40°C
  • Environmental Resistance High resistance to salt spray and oil spray
  • Hazard Mitigation Designed for environments free from explosive danger, corrosive gases, or metal-damaging conductive dust
  • Operating Altitude Suitable for altitudes up to 2000 meters (<2000m)

Product Specifications & Business Terms

Parameter Details
Gross Weight 20pcs / 21kg
Dimension 65 * 29.5 * 29 (cm)
M.O.Q 20pcs (Samples Excepted)
Payment Term T/T, L/C, D/P, O.A
Delivery Time Usually 25 days (Negotiable for different order quantity)
Branding Options Neutral packing, OEM customization, or brand agency support
Ordering Note

1. Following information need be marked when placing an order:

  • Product name, Model & Frame level & breaking capacity
  • Poles
  • Rated current
  • Protection type
  • Quantity

2. Ordering sample:

To order the Moulded case circuit breaker, 3P frame level 400A, breaking capacity 50KA, rated current is 350A, quantity is 100 pieces, should be marked:

MCCB EBS7M-400H/3P350M/50KA 100PCS

Product Gallery

AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker
AC 500V 800V Mccb 100a 3p 400 Amp 630a 3 Phase Circuit Breaker

Quality Standards & Certifications

QUALITY is our CULTURE. With qualified raw materials and components, all products are manufactured to defined specifications, applying ISO9001 quality control system and in compliance with relevant international approvals, such as RoHS, CE, CB, SEMKO, TUV, KEMA. A CNAS approved laboratory enables the development and testing of new products to meet variable markets' tailored demands. Branded and OEM/ODM products are widely served for residential, commercial and industrial applications in 60+ countries and districts.

Why Choose Us Quality Infographic
Certifications Display
Technical FAQ Banner

Frequently Asked Questions (FAQ)

Q1: What is the main function of an MCCB?
A Moulded Case Circuit Breaker (MCCB) is designed to protect electrical circuits from excess current, which typically causes overloads or short circuits. It acts as an automatic switch that shuts off power to prevent system damage.
Q2: What breaking capacity options are available for this series?
We offer multiple breaking capacity ratings classified by type letters, including B (20kA), C (35kA), S (50kA), H (65kA), G (85kA), and X (100kA) to fit various industrial safety environments.
Q3: Can the MCCB be operated in demanding atmospheric conditions?
Yes, it operates reliably within temperatures of -5°C to +40°C and features strong resistance to salt spray and oil mist. It is designed to function well up to altitudes of 2000m, provided the environment is free from explosive hazards and conductive dust.
Q4: Do you offer OEM custom manufacturing services?
Yes, we provide extensive OEM/ODM manufacturing customization. We can supply the products either under neutral packaging, custom specifications, or help you establish your position as a local market distributor.
Q5: What details should I provide when placing an order?
To process your order efficiently, please supply the product name, exact model and frame level, breaking capacity, poles (e.g., 3P or 4P), rated current, protection type, and your final order quantity.
Q6: Which safety approvals and quality standards do these breakers comply with?
Our manufacturing follows strict ISO9001 guidelines, and the products are fully compliant with major international standards and certifications, including CE, RoHS, CB, SEMKO, TUV, and KEMA.
